Bombardier Challenger 605

The Bombardier Challenger 605 is the refined evolution of the legendary 600 series, specifically designed to enhance the passenger experience while maintaining the rugged reliability of its predecessor, the 604. Introduced in 2006, it features a more spacious-feeling interior thanks to larger windows and significantly upgraded cockpit technology.

1. Performance & Range

The Challenger 605 is a true transcontinental performer, capable of non-stop missions across North America or the Atlantic with high efficiency.

  • Maximum Range: 4,000 nm (~7,408 km)
  • High-Speed Cruise: Mach 0.82 (470 ktas / 541 mph)
  • Typical Cruise Speed: Mach 0.80 (459 ktas)
  • Maximum Operating Altitude: 41,000 ft (12,497 m)
  • Takeoff Distance (MTOW): 5,840 ft (1,780 m)
  • Landing Distance: 2,360 ft (719 m)

2. Interior & Cabin Dimensions

Known for having one of the widest cabins in its class, the 605 focuses on “usable space.” The windows are 30% larger and positioned higher than previous models to provide more natural light and better viewing.

  • Passenger Capacity: 10–12 (typical executive configuration)
  • Cabin Height: 6.1 ft (1.85 m)
  • Cabin Width: 8.2 ft (2.49 m)
  • Cabin Length: 28.4 ft (8.66 m)
  • Baggage Capacity: 115 cubic feet (fully accessible in-flight)
  • Amenities: Upgraded LED lighting, a redesigned galley for better meal service, and an ergonomically improved lavatory

3. Weights & Capacities

The 605 improved upon the 604 by optimizing weight distribution, allowing for a 200 lb increase in payload capacity.

  • Max Takeoff Weight (MTOW): 48,200 lbs (21,863 kg)
  • Max Landing Weight: 38,000 lbs (17,237 kg)
  • Maximum Payload: 4,850 lbs (2,200 kg)
  • Fuel Capacity: 19,852 lbs (9,005 kg)

4. Technical Systems

  • Engines: 2 × General Electric CF34-3B turbofans
  • Thrust: 8,729 lbf each (17,458 lbf total)
  • Avionics: Rockwell Collins Pro Line 21 suite with four large high-resolution displays
  • Notable Features: Includes Electronic Flight Bag (EFB) capability and a rounded tail-cone design distinguishing it from earlier Challenger models

The Bombardier Challenger 605 remains a cornerstone of the large-cabin market. With its exceptionally wide “stand-up” cabin and the versatility to handle long-range missions with ease, it is a premier choice for those who value time, comfort, and a world-class travel experience.
